True RMS Benchtop Digital Multimeter
Ideal for the service bench or in the classroom, this unit measures AC/DC voltage and current, resistance, capacitance, frequency, transistor hFE and temperature. It also provides diode and audible continuity test.
Features:
AC or battery operation
6000 count, 3-3/4 digit display
USB and RS232 interface
Fused current measurement to 10A
AC or AC+DC TRMS measurement
Backlit display
10MΩ input impedance
Ultra sensitive 3,000MΩ input impedance on 600mV range
Switchable auto/manual range
Detailed 50 page instruction manual
Included Accessories:
Test leads
Alligator clip adaptors
Temperature probe
RS-232 and USB interface cables
Datalogging software
Specifications
Ranges:
DC Voltage: 600mV, 6V, 60V, 600V, 1000V
AC Voltage: 600mV, 6V, 60V, 600V, 1000V
DC Current: 60µA, 6mA, 60mA, 600mA, 10A
AC Current: 60µA, 6mA, 60mA, 600mA, 10A
Resistance: 600Ω, 6KΩ, 60KΩ, 600KΩ, 6MΩ, 60MΩ
Capacitance: 6nF, 60nF, 600nF, 6µF, 60µF, 600µF, 6mF
Temperature: -40ºC ~ 1000ºC, -40ºF ~ 1832ºF
Frequency: 10Hz ~ 50MHz
Input Impedance: 10MΩ (3GΩ on 600mV range)
Dimensions: 4-1/4" (H) x 8-1/2" (W) x 11" (D)
Accuracy:
DC Voltage: ±(0.3%+1)
AC Voltage: ±(0.5% +2)
DC Current: ±(0.5%+1)
AC Current: ±(0.8%+2)
Resistance: ±(0.5%+1)
Capacitance: ±(2%+5)
Temperature: ±(1%+3)
Frequency: ±(0.05%+3)
